120W Mixing Amplifier with Bluetooth MP3 FM 1.5U Desktop Digital Amplifier OEM ODM

Model Number : PD-120MF

Certification : CE

Place of Origin : Guangdong, China

MOQ : 20

Supply Ability : 5000+

Delivery Time : 30

warranty : 1-year

dimension : 260*250*66

Watt : 120W

Frequency response : 80HZ-20KHZ+/-1DB

Recommended use : for televisions, For DVD players, for gaming consoles, for computers, for music players, For surround sound systems

Contact Now

Small Size Application Mixing Amplifier 120W Digital with a Screen

The PD-120MF is a compact, high-performance D-class power amplifier engineered for professional public broadcast and multi-room audio systems. With a 120W rated output, it delivers clear, distortion-free audio to meet the needs of retail spaces, offices, restaurants, and small commercial venues.

This amplifier supports multiple input options including Bluetooth, USB, and SD card, giving you the flexibility to play music from smartphones, laptops, or local media files. Its wide frequency response of 80Hz–20KHz ±1DB ensures balanced audio reproduction, from rich lows to crisp highs.

With a THD of ≤0.1% and an SNR of ≥70dB, the PD-120MF maintains exceptional sound clarity even at high volumes. It also features AUX and MIC inputs, with sensitivities of -12dB and -40dB respectively, making it easy to connect microphones for announcements or live speech.

Designed for reliability, the PD-120MF operates on a stable AC220V/50Hz power supply. Its space-saving design allows for flexible installation in racks or wall-mounted setups, while the efficient D-class circuitry reduces energy consumption and heat generation.

Whether you're building a background music system or a public address solution, the PD-120MF combines robust performance, versatile connectivity, and user-friendly operation to elevate your audio experience.

Technical Specifications

Model	PD-60MF	PD-80MF	PD-120MF	PD-180MF	PD-240MF
Input Voltage	AC220V/50HZ
Rated Power	60W	80W	120W	180W	240W
AUX Sensitivity	-12DB
MIC Sensitivity	-40DB
Frequency Response	80HZ-20KHZ+/-1DB
THD	THD≤0.1%
SNR	≥70DB
Line Output	0
Operating Temperature	-5℃-80℃
Operating Humidity	20%-80%
Dimensions (mm)	260×250×66
